Hydraulic, double-acting
Space-saving, compact Piston Seal with integrated guiding elements. Excellent static sealing capacity. Suitable for small housings.
Talk to us now
Space-saving, compact Piston Seal with integrated guiding elements. Excellent static sealing capacity. Suitable for small housings.
Temperature Range | Max Speed | Max Pressure | Sealing Element | Back-up Ring |
-30 °C … to +100 °C | 0.5 m/s | 250 bar (3600 psi) | ECOPUR | ECOTAL/ECOMID |
-20 °C … to +100 °C | 0.5 m/s | 250 bar (3600 psi) | H-ECOPUR | ECOTAL/ECOMID |
-40 °C … to +100 °C | 0.5 m/s | 250 bar (3600 psi) | T-ECOPUR | ECOMID |
-50 °C … to +100 °C | 0.5 m/s | 250 bar (3600 psi) | T-ECOPUR | ECOTAL |
-20 °C … to +100 °C | 0.7 m/s | 250 bar (3600 psi) | S-ECOPUR | ECOTAL |
-30 °C … to +100 °C | 0.5 m/s | 250 bar (3600 psi) | G-ECOPUR | ECOTAL/ECOMID |
