Hydraulic, single-acting
O-Ring-activated asymmetric PTFE Piston Seal, low friction. Suitable for extremely low or high speeds. Suitable for positioning facilities.
Talk to us now
O-Ring-activated asymmetric PTFE Piston Seal, low friction. Suitable for extremely low or high speeds. Suitable for positioning facilities.
Temperature Range | Max Speed | Max Pressure | Glide ring | Energizer |
-30 °C … +100 °C | 0.5 m/s | 400 bar (5800 psi) | ECOFLON 2/3/4 | NBR (70 Shore A) |
-20 °C … +200 °C | 0.5 m/s | 400 bar (5800 psi) | ECOFLON 2/3/4 | FPM/FKM (75 Shore A) |
-50 °C … +150 °C | 0.7 m/s | 400 bar (5800 psi) | ECOFLON 2/3/4 | EPDM (70 Shore A) |
-60 °C … +200 °C | 0.5 m/s | 400 bar (5800 psi) | ECOFLON 2/3/4 | MVQ (70 Shore A) |
-200 °C … +80 °C | 0.5 m/s | 400 bar (5800 psi) | ECOPE | MVQ 70/ECOSIL |
