Hydraulic, double-acting

Compact Rod Seal with almost no dead spots as required for applications in the food and pharmaceutical industries. Also commonly used as O-ring replacement, because design with interference-fit on outside diameter maintains non-twisting in dynamic applications.

 Temperature Range  Max Speed  Max Pressure Material
-30 °C … to +110 °C 0.4 m/s 400 bar (5800 psi) ECOPUR
-20 °C … to +110 °C 0.4 m/s 400 bar (5800 psi) H-ECOPUR
-20 °C … to +110 °C 0.5 m/s 400 bar (5800 psi) S-ECOPUR
-50 °C … to +110 °C 0.4 m/s 400 bar (5800 psi) T-ECOPUR
-30 °C … to +110 °C 0.4 m/s 400 bar (5800 psi) G-ECOPUR
